SCITOO Trailer Hub with Brake Drum 8 Lug on 6.5 Hub 12X2 25580 x 14125A Bearing fit for 7000 lbs axle Trailer Hub Assembly

Package Quantity:1x brake drum1x inner cone bearing1x outer cone bearing1x Grease seal 1x d-ust caps with rubber plug8x cone wheel nutsParameter:25580 inner cone bearing14125A outer cone bearing12"X2" Grease seal 2.25" x 3.371" seal EZ lube grease cap with rubber plug8 on 6.5"cone wheel nuts, 1/2" - 20 threadFit For 7000 lbs axleInstallation Instructions:Step 1: Take away the existing d-ust cap, cotter pin, castle nut, washer and hub. Take away any remaining grease from spindle. Inspect For spindle For wear or damage.Step 2: Slide new hub onto spindle. Using a torque wrench, tighten the new castle nut to 30-40 foot-lbs. Turn hub to ensure proper bearing seating‚ Loosen the castle nut until loose enough to turn the castle nut with you fingers. Re-tighten the castle nut finger tight.Step 3: Install cotter pin through the hole in the spindle. If the hole is covered by the castle nut, loosen the castle nut to the nearest hole so that the cotter pin can be installed. The hub should rotate freely when spun by hand, and there should be no movement when the hub is pulled back and forth. Bend the legs of the cotter pin to ensure the cotter pin and castle nut will not loosen.Step 4: Install the d-ust cap with the d-ust cap installation tool. Use a mallet or hammer, only strike the d-ust cap tool and not the d-ust cap(Helpful hint):Place piece of wood over the d-ust cap tool.Step 5: Start all nuts by hand to prevent cross threading. Tighten the lug nuts in stages. Following the sequence and torque stages per your specific hub and wheel size. Wood block(not supplied)

• [Fitment]:1x Hub 1x Inner bearing（L25580) 1x Outer bearing （L14125A） 1x Seal 1x Dust Cap 8x wheel nuts
• [Reference OE Number]:L14125A x L25580；12X2 ,Grease seal 2.25 x 3.371 seal,EZ lube grease cap with rubber plug,Wheel Bolt Pattern 8 Lug on 6.5
• [Package Including]:1x Hub 1x Inner bearing（L25580) 1x Outer bearing （L14125A） 1x Seal 1x Dust Cap 8x wheel nuts
• [Function]:Trailer Wheel bearing assembly play an integral role in keeping trailers rolling along. The trailer wheel hub assembly connects the trailer tires to the trailer axle and facilitates their spin
• [Note]:A potential cause For bearing failure is the castle nuts being over tightened. Castle nuts should be just slightly more than hand tight. If too tight this will put excessive weight on the bearings and could lead to premature failure. I suggest an inspection of the tires on the affected wheels
